Hydraulic light tower

Lighting Tower KLT-10000 The unique articulated hydraulic mast is ideal for the mining industry,as well as use on railroad,municipal and large construction sites. Features of Lighting tower KLT-10000 1.Articulated hydraulic mast provides maximum flexibility and control for quick, effortless light positioning. 2.28 foot vertical,20 foot horizontal outreach and 360°power rotation. 3.8 foot 2 inch stowed length provides for ease of transport for towing or transportation on a trailer or container. 4.Optional environmental spill containment to meet local regulations or for use in sensitive areas. 5.Light fixtures plug in weatherproof receptacles box at top of tower with CE approved connectors. 6.Individual plug-in ballasts installed in galvanized steel boxes. Can be replaced without disconnecting wiring terminals. 7.Control panle is inside,away from the elements.Houses main and branch circuit breakers and hourmeter. 8.Gavanized outriggers with pre-set position stops ensure quick and proper spacing. 9.Single point lifting eye and forklift pockets provides for easy loading and unloading. 10.Optional Australian mining configuration designed specially to meet Australian regulations and mining application requirements. Description KLT-10000 Engine VERTICAL,WATER COOLING,FOUR STROKE Make/Model KM385D Cooling Water Kw(Hp) at Continuous 12(16)/17(23) Revolution(RPM) 1500/1800 Fuel Capacity(Liter) 100 Contineious Run Time 60hours Number of Cylinders 3 Displacement L(cu, in) 1.532 Engine shutdown protection LOW OIL PRESSURE, HIGHT WATER TEMPRETURE, HIGHT OIL TEMPRETURE, OVER SPEED Exhaust gas emmission EPA APPROVAL OPTIONAL Alternator Make/Model BRUSHLESS TFDW-8KW/10KVA Output 8KW/10KVA Frequency 50/60 Insulation H Type of bearing/Brush SINGLE/BRUSHLESS SELF EXCITATION Available Receptacles 220V/45A Lighting METAL HALIDE, SINGLE ENDED, 1000W Brand Type of Lamp METAL HALIDE, SINGLE ENDED Lamp No. 4 Housing Materials ALUMINUM REFLECTOR HOUSING Mast Tower Type MULTI-SECTIONS TELESCOPING HYDRAULIC MAST 9 M Total Height 9M, CAN BE ROTAED 360 DEGREE Operate for Extends HYDRAULIC DRIVE MAST Traveling RETRACTS AND STOWS HORIZONTALLY FOR TRAVEL TOWER IS LOCKED INTO POSITION TO PREVENT DURING TRAVEL Outriggers Hydraulic outriggers 4 Trailer/Cabin WITH THE OUTRIGGERS EXTENDED AND ALL JACK DOWN Towing Type RING HITCH Cabin WITH TWO DOORS ACCESS FOR EASY MAINTENANCE WITH HANGER FOR HANDLING DETACHABLE ROOF Electric-Shutdown protection Electric MCCB-MCB EMERGENCY STOP IP 56 Weight 850KG Packing Size 2300×1650×1800MM 20GP 4 SETS
