| Output Type |
AC Single Phase |
| Place of Origin |
Fujian China (Mainland) |
| Brand Name |
CAMEL |
| Model Number |
KDE5500 |
| Speed |
3000/3600RPM |
| Frequency |
50/60Hz |
| Rated Power |
4.5/5.0 |
| Rated Voltage |
110-240 |
| Rated Current |
18.3A |
Open frame diesel generator 5KW ♦Specification Model:KDE5500CL/KDE5500CLE/KDE5500CX/KDE5500CXE Rated Frequency [Hz]:50/60 Rated Output [KVA]:4.5/5.0 Max. Output [KVA]:5.0/5.5 Rated Voltage [V]:110,120,220,230,240,110/220,120/240 Rated Rotation Speed [rpm]:3000/3600 Phase Number:Single Phase Power Factor [cosΦ]:1.0 Excitation:Brushless, Self-Excitation DC Output:12V/8.3A Dry Weight [kg]:90(102*) Dimension: L×W×H [mm]:700×465×600 Engine Model:KM186FAG3(KM186FAG3E*) Displacement [cc]:418 Bore × Stroke [mm (in.)]:86×72(3.39×2.83) Continuous Output [hp]:7.7 / 8.6 Starting System:Recoil or Recoil/Electric Fuel Tank Capacity [L]:12.5 Lubricating Oil Capacity [L]:1.65 Low Oil Pressure Alarm System CL(E): Without / CX(E): With (*) means: Electric Starter
